Push Button Switch
Micro Switch Push Button Switch Waterproof Micro Switch Rocker Switch Toggle Switch Slide Switch Indicator Light Other Switch
Detail
Specification:
Rating: 12VDC, 50mA
Contact Resistance:100mΩ Max(initial)
Insulation Resistance:100mΩ MIN
Breakdown Voltage: 250VAC for 1 minute
Operating Force: 250±50gf
Total Travel: 0.4±0.15mm
Operating Temperature: -20℃～70℃
Life Cycle: 100,000 Cycle
Function: Momentary
Application:
Audio/ Visual
Computer Peripherals
Consumer Electronic
Instrumentation
Telecommunication
Medical Equipment
